How to avoid horizontal stacks shifting margins?

[retroflexivity]

I am not certain whether it is intended or a bug, but, when using stack with a horizontal direction, max width is calculated for each element independently, resulting in a shifted right page margin.

E.g. the following code

this is a #h(1fr) normal paragraph
#stack(dir: ltr, "(1) ", [this is a #h(1fr) stack])

results in the following placing:

The right margin of the stack is shifted to the right by the width of (1) . (should be noted that this is not fr-specific and affects line breaking as well)

If this is indeed intended, my question is, what, if not stack, should be used for creation of e.g. custom list-like layouts?

[Andrew]

Hello. Please read How to post in the Questions category before posting a question (from the pinned topic).

@reknih

If your question pertains to a bit of Typst markup you have problems with, put it in the question body! You can syntax-highlight Typst code by wrapping it in ` ```typ … ````. It will then look like this:

#set font(size: 12pt)

Hello from *Typst* at $ pi.var + 1 $ o'clock!

If you need to highlight a code or math mode snippet instead, the language tags typc and typm do that, respectively.

[Andrew]

Hmm, I think it is a bug, since by default everything must follow the set margins. You should open an issue about it.

@retroflexivity

If this is indeed intended, my question is, what, if not stack, should be used for creation of e.g. custom list-like layouts?

It depends on how your list layout supposed to work. Internally, lists are implemented through grid. typst/crates/typst-layout/src/lists.rs at ad539ef4ed0551a7eb22f7c9c0ab1c0fd1b59209 · typst/typst · GitHub

---

Horizontal stacks shift right margin

[retroflexivity]

Thank you! Grids do seem more suitable, and avoid the bug.

I’ll file an issue right away.

[SillyFreak]

Also relevant, this Discord discussion:

@laurmaedje

TLDR: Stacks haven’t really been touched in ~2 years and are wonky and broken

– Discord, 2024-10-16T00:00:00Z

It’s definitely still an issue, but I’d just prefer grid out of principle. I’m not aware of something that can be done with a stack, but not a grid.

[retroflexivity]

Yeah, I’ve switched to a grid already and it’s working great, thank you

Which leads me to a question: why is stack a thing anyway, given there is grid?

(sorry if it’s not ok to bump a closed topic)

[SillyFreak]

It’s just a small follow-up, so not too bad imo.

I assume just history. At some point the two functions were considered to be solutions for different use cases (and the defaults of the two may still support that view), but once grid became the “dominant” tool for this kind of task, development of stack stalled. Since you have to actively spend effort to remove something (not just the code, deprecation first and then updating the docs) it just didn’t happen yet.
